VITORIA RHG-M110 (M3-M110) VERTICAL

Description

This model has an additional device to put the tapping head in horizontal position. To change from vertical position to horizontal and the other way around takes about 15 min.

• TAPPING CAPACITY

METRIC: M3-M110
INCHES: BSW 1/8 – 3″1/2, BSP 1/8 – 8″

• TECHNICAL DATA

CAPACITY M3-M110
R.P.M. 11-450
MAXIMUM PRESSURE 200 Kg /cm²
MOTOR 10 HP
VOLTAGE 380/400/415 3 PHASES
SPEED CONTROL ELECTRONIC
ARM LENGTH 1.000 mm
TABLE WORKAREA TOTAL
QUICK CHANGE CHUCK N.º 2-1
OIL TANK 50 LITRES
WEIGHT 1300 Kg.

• SERIAL EQUIPMENT

ARTICULATED ARM WITH 4 SLIDING BARS
T-SLOT TAPBLE OF 1200 X 800 mm.
FREQUENCE INVERTER (HZ)
DIGITAL RPM INDICATION SCREEN
LEFT AND RIGHT TAP CONTROL
ELECTRIC BOX
POSITION DIODES
HYDRAULIC GROUP
HYDRAULIC PUMP
GEAR REDUCTOR
TAPPING SAFETY SYSTEM
QUICK CHANGE CHUCK FOR TAP-HOLDERS
HYDRAULIC PRESSURE MANOMETER
HYDRAULIC PRESSURE REGULATION KEY
MANOMETER PROTECTION KEY
HYDRAULIC OIL THERMOMETER
SILEMBLOC LEVELLING FEET
COOLANT SYSTEM 0,24KW
TAPPING DEPTH DETECTOR
